OEM/ODM M90 Stator Generator/ Brushless Stator

The stator is elector motor or motor still part., The stator made of Stator iron core,Stator winding and machine base. The stator main role is the rotating magnetic field is cut by magnetic lines of force to generate (output) current.

We got ISO/TS 16949 Certification passed in 2013, after produce many OEM stator assemblies, The annual output is around 170,000 pieces.

The stator consists of the base, the stator core, the coil, and other structural parts that fix these parts. The machine base is used to fix the iron core. For suspended generators, the machine base is used to bear the full weight of the rotating part; the iron core is part of the magnetic circuit of the generator; the coil forms the generator's circuit.
Machine base
The frame is usually cast iron, the large asynchronous motor frame is generally welded with steel plates, and the miniature motor frame is made of cast aluminum. There is a heat dissipation rib on the outside of the frame of the enclosed motor to increase the heat dissipation area. Vent holes are provided at the end covers of the frame of the protective motor to allow the air inside and outside the motor to directly convect to facilitate heat dissipation.
The main frame of the generator is used as the supporting structure of the stator core lamination, which bears the torque of the stator and transmits it to the feet; it forms the channel of cooling gas and forms the supporting structure of the bearings, the frame and the cooler.
Stator core
The stator core is the main magnetic circuit of the stator, and it is also the mounting and fixing component of the stator windings. The stator core is composed of fan-shaped punching pieces, ventilation slot pieces, tooth pressure plates, tension bolts, brackets, positioning ribs and other components.
Coil
Most of the stator windings of large hydro-generators use double-layer wave windings of strip coils (also known as wire rods). The characteristics of strip wave windings are that they have fewer end connections and are easy to replace. For water-cooled generators, single-layer wave windings can also be selected, which can simplify the cooling water pipeline.

Stamping Parts product attributes

FAQ

Q: Are you a factory?
A: We are a 32-year-old factory, we pick up OEM/ODM orders.

Q: When can I get a quote?
A: We will quote you within 24 hours after receiving your inquiry. If you are in urgent need of price, please call us or let us know in your email address so that we can respond to your inquiry first.

Q: How to customize (OEM/ODM)?
A: If you have product drawings or samples, please send them to us and we can customize them according to your requirements. We will also provide our professional advice on products to maximize design performance..

Q:How long is your delivery time?
A: It usually takes 5~15 days, depending on the quantity you need. If time is urgent, you can arrange it.

Xinxiang Huihuang Spring Co.,LTD.

is one of the largest manufacturers of metal springs and stampings in China. For more than 30 years, we have been offering custom-made spring products to our customers. With our own 37 patents, 3 inventions, 5,000 specifications, modern production equipment, and strict system guidelines, we have the ability to manufacture springs of almost any shape and type, with an annual output of 500 million springs. Products have passed ISO9001 ISO14000 ISO18000 IATF16949 certification. Our team consistently produces the highest quality products, our greatest asset is experienced and dedicated Hui Huang employees, each of whom receives continuous training throughout their careers to ensure we remain industry leading.
